«Radar-IQ» -
Area Protection Solution
Area Protection Solution
Aimed to protect the territory of critical infrastructure facilities, special and secure facilities, as well as private property from ground and air threats.
Air and Ground threats are detected by active radar technology long before they cross the protected perimeter line.
This is a new security protection concept that even in fact do not require a physical fence - all threats are detected up to the virtual perimeter line.
How does «Radar-IQ» works?
Target detection
The Radar-IQ perimeter protection system is based on Pulse-Doppler radar-type motion detectors. Our radar not only detects multiple moving targets, but also collects information about it: its size, speed, direction of movement, as well as spatial position of the target.
Target processing
All detected targets are analyzed by CORE-IQ AI controller, which sorts targets, determining their class (drone / bird / man / machine / animal) and evaluate level of threat for a particular site. When the most priority target is sorted out, it should be confirmed optically and accordingly CORE-IQ controller aims the DV-EYE camera module to see the target.
The video analytics recognizes and confirms the shape of a detected target in the frame. Further, the video analytics is able to independently control the DV-EYE camera module, allowing you to track the target based only on the data from the camera. CORE-IQ Video analytics works permanently while the camera is moving and zooming.
The video analytics recognizes and confirms the shape of a detected target in the frame. Further, the video analytics is able to independently control the DV-EYE camera module, allowing you to track the target based only on the data from the camera. CORE-IQ Video analytics works permanently while the camera is moving and zooming.
The high level of security
The Radar-IQ system uses advanced radar technology to detect an intruder long before he crosses the border of the facility. Thus, the Radar-IQ system is designed to raise the level of facility security to a whole new level, helping to prevent incidents.
Application area
The main function of the Radar-IQ system is the detection and trajectory control of the movement of UAVs and ground objects in protected areas.
Potential threats such as UAVs, humans, cars or boats are detected by active radar technology long before they cross the perimeter line.
The main function of the Radar-IQ system is the detection and trajectory control of the movement of UAVs and ground objects in protected areas.
Potential threats such as UAVs, humans, cars or boats are detected by active radar technology long before they cross the perimeter line.
«Radar-IQ» Advantages
- Ready to useRadar and Camera are coupled by the construction and factory calibrated, therefore the product is completely ready for use.
- No "blind spots"Full 360 ° view of both Radar and Camera (angle of view 360 ° in azimuth and >180° in elevation).
- High protection efficiencyBalanced detection area, low false alarm rate, minimal impact of precipitation.
- High quality of object detectionSolid state radar technology with high scanning frequency (35'000 p/s).
- Open protocolAbility to use the "Radar-IQ" system as part of third-party VMS or C&C SW solution.
- High quality of the tracked object videoSpecially developed camera control algorithms (based on radar data and neural network image processing) provide smooth picture of tracking object when the camera and zoom are constantly moving.
Scope of «Radar-IQ» modules:
1. Module "Radar": - A Pulse-Doppler Radar motion detector.
2. Module "DV-EYE" - PTZ camera of original construction. A module that allows you to combine a Radar and a PTZ camera, each with 360-degree circular views, into a single device without "blind" zones and with a single calibrated polar coordinate system.
3. Module "CORE-IQ" - Multispectral Controller with Artificial Intelligence. The module combines all solution components into a single system.
4. «Radar-IQ Manager» - Software for the real time system monitoring Workstation.
It also provides all necessary instruments for system components set up and configuration.
2. Module "DV-EYE" - PTZ camera of original construction. A module that allows you to combine a Radar and a PTZ camera, each with 360-degree circular views, into a single device without "blind" zones and with a single calibrated polar coordinate system.
3. Module "CORE-IQ" - Multispectral Controller with Artificial Intelligence. The module combines all solution components into a single system.
4. «Radar-IQ Manager» - Software for the real time system monitoring Workstation.
It also provides all necessary instruments for system components set up and configuration.
System features
All radars of «Radar-IQ» have a built-in DSP processor, which processes all reflected echo signals and generates target data. Thus, radar transmits target trajectories data after the targets were evaluated.
"Radar-IQ" uses solid-state technology, which allows not only to scan space with a frequency of up to 35'000 pulses per second, but also to update the track information of the detected target 4 times per second. This allows you to detect a new target in an average of 2 seconds and track the movement of up to 96 targets simultaneously.
All Radars have automatic sensitivity threshold adjustment, which adaptively adjusts to the current level of passive interference (Clutter). In this case, the automatic selection of the sensitivity threshold is created in each of the 24 visibility zones independently, depending on the level of passive interference in each of them.
Depending on the operating conditions in the "Radar-IQ" system, you can choose one of 4 levels of trajectory sensitivity adjustment. The higher the sensitivity, the faster (based on smaller statistic sample), the target will be detected but with more probability to detect false target.
The C-Band frequency (5.8 GHz) and original algorithms of radar data processing allow to achieve reliable target detection in challenging weather conditions: rain, snow or fog.
The "Radar" sensor module has a kinematic free design. In other words, the "Radar" module has no moving or rotating parts, including passive cooling, which guarantees high reliability in 24/7 operation and more than 60,000 hours of uninterrupted operation.
