DR-500/DR-1200
3D radar with full dome coverage
Compact Pulse-Doppler radar for detecting of moving targets in airspace.
Protected area 4 500 000 sq.m.
DOWNLOAD DATASHEET
Designed to detect and track small UAVs:
Medium (DJI Inspire type)
Mini (DJI Phantom type)
Micro (DJI Mavic type)
Can detect ground-based moving targets in the protected area:
Humans
Cars
Boats
Features:
Track update 4 times per second
No moving parts
Zero maintenance cost
DPA function (Dynamic Power Allocation)
Extends the detection range up to 700 m
Compact size 360 x 180 mm
Sealed housing
PoE +
One-cable connection
Fast installation
Weather resistant performance 24/7
Technical features
Radar Features; DR-500
Radar type; Impulse Doppler, Solid, Non-Kinematic Operating Frequency; C-Band (5.6-5.9 GHz) Radar azimuth/elevation angle ; 360° x 180° Distance (standard/DPI mode, azimuth <180°); 500 m / 700m Detection Range examples: DJI Phantom 4; 450-500m DJI Mavic 2; 350-500m Targets tracked simultaneously; Up to 250 Minimum RCS (Radar Cross-Section); 0,01 m² – a drone False alarm filtering; Intellectual Power supply/Data transmission; PoE+ / Ethernet Operating temperature; From -40°C to +60°C
Button
Radar Features; DR-1200
Radar type; Pulse Doppler Solid State Non-KinematicImpulse Doppler, Solid, Non-Kinematic Operating Frequency; C-Band (5.3-5.9 GHz) Radar azimuth/elevation angle ; 180° / 360° Distance (standard/DPI mode, azimuth < 180°); 1200/1400 m Detection Range examples:; DJI Phantom 4; 1050-1200 m Dji Mavic-2; 900-1200 m Targets tracked simultaneously; Up to 250 Minimum RCS (Radar Cross-Section); 0,01 m² - a drone False alarm filtering; Intellectual Power supply/Data transmission; 48VFC (150 W)/ Ethernet 150 W Operating Temperature; -40°C to +60°C
