GR-800
2D Ground Surveillance Radar
Compact Pulse-Doppler radar for detecting of moving ground targets
Protected area 2 100 000 sq.m.
DOWNLOAD DATASHEET
Designed to detect:
Humans
Cars
Boats
Features:
Track update 4 times per second
Azimuth accuracy ± 0.50
No moving parts
Zero maintenance cost
DPA function (Dynamic Power Allocation)
Extends the detection range up to 1200 m
Compact size 360 x 240 mm
Sealed housing
PoE +
One-cable connection
Fast installation
Weather resistant performance 24/7
Technical features
Radar Features; GR-800
Radar type; Pulse Doppler Solid State Non-Kinematic Operating Frequency; C-Band (5,7÷5,8 GHz) Detection Range (general / maximum DPA); 800 m / 1200m Instrumental Detection Range with DPA function: FOV - 3600: Human/ Car / Boat; 800m FOV - 1800: Human/ Car / Boat; 1000m FOV - 1200: Human/ Car / Boat; 1200m Simultaneous Tracking Targets; 250 Minimum RCS (Radar Cross-Section); 0,25m² - Human Auto target classification; Boat / Human / Car False Alarm Filter; Intellectual Sensitivity (minimum radial speed);14 cm/sec Power / Data; PoE+ / Ethernet Operating Temperature; - 40°C to + 60°C
