DV-EYE
Fixed central pole PTZ camera
The unique DV-EYE camera design provides full upper hemisphere all around view both for radar and camera.
The DV-EYE camera and the DR-500 or GR-800 radar are factory calibrated and complement each other in the Radar-IQ perimeter protection system.
DOWNLOAD DATASHEET
The modular design allows additional equipment to be jointed with the camera.
For example thermal imaging modules, IR and laser illumination.
Features:
Low power
Direct drive mechanism
Local recording
IR Infrared lighting
360° view
High Security and precision
Specifications
DV-EYE Features; DV-EYE-v30xir250
General features:; Ambient temperature; - 50°С + 60°С (with additional heater) * Protection; IP 67 Weight; 12 kg Power; 24V / 30V DC / 100W Camera:; Camera sensor; Video 1/2.8” Exmor-R / 2.13 Mpix Lens; f=4,3-129mm (30x) / 63,70 – 2,30 Sensitivity; color – 0,0013lux / BW - 0,0008lux Codec; 1920x1080 / Dual stream IR lighting:; IR350 meter PT drive:; Pan; 0.1 – 120°/sec; 360° constant pan Tilt; 0.1 – 120°/sec; +/- 180° Presets; 360°
